DESCRIPTION
- The hospital bed is constructed from high-quality steel with a durable powder-coated finish, ensuring excellent corrosion resistance, structural strength, and long service life in clinical environments.
- The bed platform is made of high-strength HPL (HPL laminate) material, offering superior rigidity, deformation resistance, and reliable patient support.
- The bed is equipped with Ø200 mm central-controlled silent casters, with four corner brake pedals that allow convenient and efficient locking operation by medical staff.
- A central fifth-wheel steering system enables switching between directional control and free-movement mode, improving straight-line stability and maneuverability during transport.
- An ergonomic control handle operates a silent gas spring system, allowing smooth and precise adjustment of the backrest angle for patient comfort and clinical positioning.
- An integrated under-bed tray is designed for storage or oxygen cylinder placement, with a load capacity of up to 10 kg, ensuring practical clinical utility.
- A manual crank system is provided for knee section adjustment, allowing a controlled elevation range of 0–40° to improve patient positioning and comfort.
- The bed is equipped with Ø100 mm protective bumper wheels around the frame, designed to prevent collision damage and enhance safety during movement.
- IV pole storage brackets are installed on both sides of the bed, along with multiple IV pole insertion sockets around the frame for flexible clinical use.
- The bed features L-shaped and U-shaped push handles with dip-coated ergonomic grips for comfortable handling. It also includes a 70 mm thick breathable waterproof mattress, a five-position stainless steel folding side rail system, and ≥1.5 mm thick 304 stainless steel posts for enhanced safety, stability, and patient protection.
