DESCRIPTION
● German German-made De’enco medical-grade micro-motor, precise, and durable.
● Independent power for each movement ensures reliable operation.
● 330mm longitudinal shift enables full-body C-arm imaging.
● Linear guide rails for smooth and stable table movement.
● Memory foam mattress—comfortable, waterproof, and easy to clean.
● Carbon fiber tabletop—low X-ray absorption, high-definition imaging.
● Antimicrobial coating for improved hygiene and infection control.
● Anti-glare ABS base—reduces eye strain and simplifies cleaning.
● Dual control systems (remote + backup) for enhanced reliability.
● Optional battery supports 50–80 surgeries; AC power available.
● One-touch reset improves post-op efficiency.
PARAMETER
| project | parameter |
| bed size | （2100×585）±10mm |
| Bed height (no mattress included) | Minimum height: (730±20) mm
Maximum height: (1030±20) mm |
| lift stroke | (300±20) mm (electric) |
| longitudinal travel of bed surface | (330±20) mm (electric) |
| cephalopodal tilt angle | Head tilt: 20°±2° (electrically adjustable)
Foot inclination: 20°±2° (electric) |
| roll angle | Left: 25°±2° (electric)
Right: 25°±2° (electric) |
| back angle | Upward tilt: 60°±2° (electrically controlled)
Lower angle: 20°±2° (electric) |
| leg fold angle | Upward tilt: 35°±2° (manual)
Lower fold: 90°±2° (manual) |
| headboard angle | Upward tilt: 40°±2° (manual)
Lower fold: 90°±2° (manual) |
|
One-touch reset feature |
|
WARRANTY
We offer a 1-year standard warranty, which can be extended upon request.
Products that fail due to manufacturing defects within one year from the purchase date will receive free spare parts and assembly instructions.
After the warranty period, spare parts are charged at cost, but technical support remains free.
