Mobile Surgical Pendant DMYL-580Y

● Adjustable instrument platforms with universal power outlets and IV pole.

● Mobile base with lockable swivel casters for stable and flexible movement.

● High-strength aluminum structure with anti-glare powder-coated finish.

DESCRIPTION

● Operating power supply: AC220V, 50Hz
● Equipped with 3 adjustable instrument platforms with side rails
● Platform size: 600 × 400 mm with rounded anti-collision design
● Mobile base size: 650 × 650 mm for stable support
● Includes 8 universal 220V/10A power outlets compatible with international plugs.
● Adjustable IV pole with anti-slip safety locking and damping lift mechanism.
● Four swivel casters with independent brakes, wheel diameter >100 mm.
● Overall equipment height exceeds 1.5 meters.
● Constructed from high-strength aviation-grade aluminum alloy.
● Surface finished with imported AkzoNobel electrostatic powder coating and anti-glare treatment.

PARAMETER

No. Accessory Name Quantity
1 Medical Pendant 1 set
2 Network Interface 1 pc
3 Power Sockets 8 pcs
4 Equipotential Grounding Terminals 2 pcs
5 Drawer 1 pc
6 Adjustable IV Pole 1 pc
7 Telephone Interface 1 pc
8 Gas Terminal Connectors 6 pcs
9 Equipment Shelves 2 pcs
10 Casters 4 pcs

WARRANTY

We offer a 1-year standard warranty, which can be extended upon request.
Products that fail due to manufacturing defects within one year from the purchase date will receive free spare parts and assembly instructions.
After the warranty period, spare parts are charged at cost, but technical support remains free.
