DESCRIPTION
● Constructed from high-strength 6063 aviation-grade aluminum alloy for durability and stability.
● AkzoNobel eco-friendly electrostatic powder coating reduces infection risks in laminar airflow environments.
● Ceiling mounting supports expansion bolt or welded installation with load capacity up to 2000kg.
● Passed seismic testing above level 7, meeting national earthquake resistance standards.
● Medical pendant joints tested for over 100,000 rotations without damage.
● Bridge-type pendant total load capacity up to 600kg; suspended pendant ≥300kg, compliant with IEC 60601-1 load testing.
● Aluminum alloy trays with double-layer hollow design, net load ≥120kg, tested to IEC 60601-1 standards.
● Full aluminum alloy drawers with damping auto-closing function and load capacity >40kg.
● Gas outlets comply with EN ISO 9170-1 standards, featuring color/shape differentiation and over 50,000 insertion cycles.
● Internal cable and gas pipeline management prevents exposure and accidental disconnection during movement.
● Gas-electric separation design maintains safe distance between medical gas terminals and electrical components.
● Protection level complies with GB4208-2008 medical standards, rated IP20.
